Cardioid studio microphone delivers warm and smooth audio reproduction in close-proximity studio and vocal applications.
Features include wide-range frequency response, bass roll off and mid-range control, and internal air suspension shock isolation.
✓ Quintessential dialog microphone with a flat, wide-range frequency response ✓ Bass roll-off and midrange emphasis (presence boost) controls accommodate a wide range of voices ✓ Shielded against electromagnetic hum and broadband interference ✓ Internal air suspension shock isolation virtually eliminates mechanical noise transmission ✓ Effective pop filter eliminates need for any add-on protection against explosive breath sounds ✓ Yoke mounting with captive stand nut for easy mounting and dismounting ✓ Classic cardioid polar pattern provides excellent off-axis rejection ✓ Rugged construction for a lifetime of regular wear and tear ✓ Ships with A7WS detachable close talk windscreen
• Type – Dynamic • Frequency Response – 50 to 20,000 Hz • Polar Pattern – Cardioid • Electromagnetic Hum Sensitivity(Typical, Equivalent SPL/milliOersted) – 60 Hz: 11 dB | 500 Hz: 24 dB | 1 kHz: 33 dB • Impedance – 150 ohms for connection to microphone inputs rated at 19 to 300 ohms. • Output Level (at 1,000 Hz) – Open Circuit Voltage: – 59.0 dB (1.12 mV) | 0 dB = 1 volt per Pascal • Switches – Bass rolloff and mid-range emphasis: Slotted response selector switches. • Cartridge Shock Mount – Internal air-suspension shock and vibration isolator. • Microphone Connector – Three-pin professional audio (XLR) • Swivel Assembly – Integrated, captive nut for ease of attachment to stand, fits 5/8 in.–27 thread. • Polarity – Positive pressure on diaphragm produces positive voltage on pin 2 relative to pin 3. • Case – Dark gray enamel aluminum and steel case with dark gray foam windscreen. • Net Weight – 765.4 g
OPTIONAL ACCESSORIES AND REPLACEMENT PARTS:
• A7WS Large Close-Talk Windscreen • RPM106 Replacement Cartridge • 537A Desk Stand • RK345 Microphone Windscreen
